C490TM
Technical specification of C490TM
| Technical data | Dim. | Value |
|---|---|---|
| Height of centers | mm | 240 |
| Swing diameter over bed | mm | 490 |
| Swing diameter over carriage | mm | 330 |
| Swing diameter over gap in bed | mm | 650 |
| Width of ways | mm | 320 |
| Distance between centers | mm | 750, 1000, 1500 |
| Bar material | mm | 50 |
| Spindle | ||
| Spindle nose DIN 55027 | № | 6 |
| Spindle nose taper | mm | 52 |
| Spindle bore | KM | 6 |
| Feed | ||
| Feed quantity | pcs. | 40 |
| Longitudinal feed range | mm/rev | 0,05 - 0,8 |
| Transverse feed range | mm/rev | 0,025 - 0,4 |
| Toolpost | ||
| Toolpost shank size | mm | 20x20 |
| Threads | ||
| Thread quantity | pcs. | 40 |
| Metric | mm | 0,5-7,5 |
| Imperial | vit / inch | 4-60 |
| Module | M | 0,25-3,75 |
| Diameter | vit / inch | 8-120 |
| Carriage | ||
| Cross slide stroke | mm | 245 |
| Top slide stroke | mm | 125 |
| Tailstock | ||
| Tailstock diameter | mm | 60 |
| Tailstock taper | KM | 4 |
| Tailstock travel | mm | 130 |
| Motor | ||
| Number of gears of main motor | pcs. | 12 |
| Range of motor revolutions | rev / min | 45-2000 |
| Motor power | kW | 4 |
| Rapid traverse motor power | kW | 0,55 |
| Coolant pump motor power | kW | 0,18 |
| Weight | ||
| For DBC 750 | kg. | 1640 |
| For DBC 1000 | kg. | 1690 |
| For DBC 1500 | kg. | 1780 |
| Size | ||
| Length for DBC 750, 1000, 1500 | mm | 2100, 2350, 2850 |
| Width | mm | 980 |
| Height | mm | 1325 |
Standard equipment
Main Motor 4KW, Electrical equipment, Coolant system with pump, Lighting, Rapid traverse,Gap bed, 200mm flange, Back cover plate along bed, 3 jaw chuck cover plate, Toolpost cover plate, Set of belts, spare cogwheel, Bolts and fittings for leveling, spindle dead center, Reduction sleeve for spindle, 4 positional toolpost, Fast-screwing tailpost, Reductor for tailpost ram, Electrodynamic brake, Polyethilene covered pallet packing, Users manual
